Specifications | Sinotruk Howo Tractor Truck 6x4 | | Chassis Model | ZZ4257S3241W (Left Hand Driving Type) | | Production Year | New truck. | | Cabin | HW76 cab, with one sleeper and two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn,air conditioner , with transverse stabilizer,with 4-point support fully floating suspension + shock absorber. | | Engine | Make: SINOTRUK Diesel 4-stroke direct injection diesel engine Engine model: WD615.47, Euro 2, 371 HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L | | Transmission | HW19710, 10F & 2R. Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2) | | Steering | ZF power steering, modol ZF8098, hydraulic steering with power assitance | | Front Axle | HF9, 1x9000 KGS Steering with doubleT-cross section beam | | Rear Axle | HC16, 2x16000 KGS Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles. Ratio:4.42 | | Propeller Shaft | Double universal joint propeller shaft with gear-shaped coupling flange | | Chassis | Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer | | Brake | Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake | | Electrics | Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light | | Tyres | 315/80R22.5, tubeless tyres with one spare tyre | | Fuel Tank | 400L | | Fifth Wheel | 90# | | Overall Dimension | 6900*2550*3200 mm |
Description:
1. Sinotruk tractor truck adopt many key technologies both from home and abroad, and it can achieve the best design and be in good conditions. 2. Humanization.easy and convenient to drive, there are many key close to touch, and it save human labors and also can make the drive focus on the driving 3. Low oil consumption. Sinotruk adopt the engine that combine the MAN and technolgoy, it has the perfect oil performance. 4. Sufficient stocked spare parts are available for you when you need to repair your tractor trucks. Applications: Towing of vehicle with a traction device, designed for towing all kinds of semi-trailers Competitive Advantage 1. Professinal Sales Team of trucks. Our target is not selling trucks, we help customers choose the best suitable trucks.
2. Fast production period, and quick arrangement of delivery.
3. Professional team for spare parts and aftersale services. |
